Vinyl flooring calculator
Vinyl plank flooring calculator:
boxes, adhesive and cost
LVP is one product installed three ways, and the method decides what else goes in the cart. Pick click-lock, glue-down or loose-lay and get boxes, adhesive by the gallon where it is actually needed, and a straight answer on underlayment.
Enter measurementsOptional
What will it cost?
Every material the calculator worked out gets its own price. Each field starts at a typical US figure so you have something to work from — change any of them to what your own supplier charges.
These prices are approximate. They are national US retail figures, and what you actually pay varies with your region, your supplier, the season and how much you buy at once. Treat them as a starting point, not a quote — always price the job from your own supplier's current figures before you order.
Your prices
More in this series
The rest of the floor
A room is rarely one material and nothing else. The measurements you have entered here carry straight across to the floor next door, and to the pad under both.
- Flooring Calculator Laminate, vinyl plank, engineered wood and parquet
- Laminate Flooring Calculator Laminate planks, boxes, underlayment, transition strips and quarter round
- Hardwood Flooring Calculator Hardwood boards, cleats or staples, rosin paper and transition strips
- Carpet Calculator Broadloom carpet, pad, tack strip, seam tape and transition bars
- Underlay Calculator Flooring underlay rolls, strip layout and joint tape
- Flooring Square Footage and Waste Measuring a room, what to subtract, and turning square feet into boxes
- Carpet Pad Thickness and Density Thickness, density and what each one is actually for
Based on your result
What you'll need
Quantities update after every calculation. Adhesive only appears when the method actually uses it.
- Vinyl plank boxes
- Full boxes including cutting waste
- Calculate above
- Adhesive
- Gallons at the spread rate of your trowel notch
- —
- Underlayment
- Only where the method and plank call for it
- —
- Transition strips
- One per doorway
- —
- Installation kit
- Utility knife, tapping block and spacers
- 1 kit
The maths
How this vinyl flooring calculator works
Area and waste work the same as any plank floor. What changes with LVP is everything after that: a glue-down floor needs adhesive measured by the notch of the trowel, and a floating one needs a pad — unless the plank already has one on its back.
boxes = ⌈ order area ÷ box coverage ⌉
adhesive = ⌈ floor area ÷ notch spread rate ⌉
spread rate = 200 / 150 / 100 sq ft per gallon
LVP is far less forgiving of a wavy subfloor than carpet or a thick laminate — every dip telegraphs through. If the floor is more than about 3/16 in out over 10 ft, flatten it first with the self-leveling compound calculator.
- 01
Measure the footprint
Each room is added together and each exclusion comes back out, measured on its own.
- 02
Apply cutting waste
Straight rows waste the least; a diagonal or herringbone lay needs the most because every plank is cut on an angle.
- 03
Round up to boxes
The order area is divided by the coverage on the pack — about 24 sq ft for most LVP — and rounded up.
- 04
Branch on the method
Click-lock takes a pad and no adhesive. Glue-down takes adhesive and no pad. Loose-lay takes neither across the field.
- 05
Measure the adhesive by the notch
A fine notch stretches a gallon over 200 sq ft; a coarse one covers 100. The notch, not the floor size, is what doubles the order.
Good to know
Vinyl plank questions, answered
A 12 by 12 room is 144 sq ft. With a 10% cutting allowance that is about 159 sq ft, and at the usual 24 sq ft a box it comes to 7 boxes. Box coverage varies more in LVP than in laminate — anywhere from 18 to 30 sq ft — so overwrite the figure with what is on your own pack.
The plank is. Rigid-core LVP has a plastic or stone-composite core that does not swell, which is why it goes in bathrooms and basements where laminate cannot. What is not waterproof is the joint: water can still get past a click seam and sit on the subfloor underneath. For a room that floods rather than splashes, glue it down.
Glue-down. A floating floor over a wet-prone room traps whatever gets under it, and a click seam is the easiest way in. Bonding the plank to the subfloor removes the void and keeps the whole assembly flat. It is more work and you will not get the planks back up cleanly, which is the trade-off.
It is set by the trowel, not the floor. A 1/16 x 1/16 in notch spreads a gallon over about 200 sq ft, a 1/16 x 1/32 in notch over 150, and a 1/8 x 1/8 in notch over 100. Using a coarser notch than the adhesive datasheet calls for doubles your cost and can leave the plank sitting on ridges.
No. Two layers of padding let a floating floor deflect far enough under foot to work the locking joints apart, and most warranties say so explicitly. The calculator drops underlayment from the order as soon as you tick the attached pad box.
Over tile, sheet vinyl or a sound wood floor, usually yes, provided it is flat and firmly attached. Over carpet, never — the pile lets the floor move. Grout lines deeper than about 1/8 in need filling first, or they will read through as lines in the new floor.
It is the thickness of the clear top film in mils, and it is what decides how long the floor lasts rather than how thick the plank is. 6 mil suits a spare room, 12 mil a family home, and 20 mil or more is what goes into a shop. It does not change any quantity here, but it moves the price per square foot a long way.
